TSM 3-ROW Radiator Shroud Brushless Fan For 1985-1996 Ford F150 F250 350 Bronco

ASI6238

In stock

SKU: TSM35022FS Barcode: ASI6238

No reviews

$479.00

Overall Size

22 1/2" H × 37 1/4" W

Fitment Notice: The fitment tool is for reference only. Please compare the dimensions, inlet/outlet sizes and positions, mounting points, and cooler connections with your original part before placing your order.

Quantity:

We Accept

U.S. Stock | Free Shipping (Excludes HI & AK)

1 Year Warranty

Official ASI Store

Do you have questions about this product?

Ask an expert!

Fitment:

Radiator Specifications

Core Design	3-Row Tube Core Racing Design
Material	Aircraft AA5083 Aluminum
Core Technology	Brazed Core Technology
Tank & Fitting Thickness	2 mm
Fin Height	6 mm
Cooling Row Spacing	3/8"
Cooling Fins	14-16 Fins per Inch
Core Size	18" H × 28 1/8" W
Overall Size	22 1/2" H × 37 1/4" W
Upper Hose	1 3/4" - Right
Lower Hose	1 3/4" - Left
Petcock Drain	OEM Style Brass Petcock Drain
Radiator Cap	CNC Machined Billet High Pressure Radiator Cap, 1.3 Bar

Vehicle Fitment

1985-1992 Ford Bronco 4.9L
1985-1996 Ford F-150 4.9L
1985-1996 Ford F-250 4.9L
1985-1996 Ford F-350 4.9L

Fan Shroud Performance Advantages

1. Premium AA5083 Marine-Grade Aluminum Construction: High-strength, corrosion-resistant alloy delivers superior durability vs. standard aluminum, perfect for harsh engine bay environments.

2. Sealed, High-Efficiency Airflow Design: Precision-fitted shroud eliminates air leakage around the radiator core, forcing 100% of fan airflow through the cooling fins for 30-50% better heat rejection than unshrouded setups.

3. Aerodynamic Vented Structure: Optimized vent design reduces turbulence, prevents hot spots, and efficiently expels hot air out of the engine compartment rather than trapping it near the engine.

4. Engine Protection & Structural Reinforcement: Secures fan blades in place, preventing contact with other engine components; reinforces the radiator core to resist vibration and road debris damage.

5. Maintains Optimal Engine Conditions: Ensures consistent, even cooling to preserve engine performance, extend service life, and improve overall ride quality.

6. Direct Bolt-On Fitment: Precision-machined for easy, no-modification installation, perfect for a clean, professional engine bay finish.

Fan Specifications

Fan Diameter	12"
Voltage	24V
Motor Type	Brushless Motor
Airflow	1800+ CFM

High-Performance Brushless Motor: Eliminates friction and wear for 10x longer service life than traditional brushed fans, with consistent, reliable performance.

Powerful Axial Cooling Design: Compact, high-torque 12-inch fan delivers massive airflow (1800+ CFM), suitable for high-horsepower engines, turbocharged builds, and heavy-duty applications.

Quiet, Vibration-Free Operation: Precision-balanced blades and motor ensure smooth, low-noise operation, even under continuous use.

Built for Harsh Environments: Sealed motor housing resists dust, moisture, and extreme temperatures, engineered for continuous-duty operation.

Maintenance-Free Performance: No brushes to replace and no regular maintenance required for hassle-free ownership.

Energy-Efficient Operation: Low power draw reduces electrical system load, making it suitable for 24V commercial, performance, and off-road applications.

Description

This TSM® AA5083 Aluminum Radiator is designed to provide maximum cooling efficiency to help prevent premature engine failure. Its lightweight, high-heat-transfer aluminum construction features a tube-and-fin design that dramatically increases surface area and enables heat to dissipate more efficiently.

This AA5083 Aluminum Radiator is at least 30%–45% more efficient than stock radiators, helping the cooling system operate more efficiently and resist temperature surges in racing applications.
